LED Sanierungseinsatz TENEO DC

LED renovation insert TENEO DC

Dimmable, VDE-certified LED retrofit solution with external driver

Das rechtssichere, eigenständige „Leuchte-in-Leuchte“-System des LED Sanierungseinsatzes TENEO DC It is extremely efficient and well-designed. Thanks to suitable lengths, classic T5/T8 fluorescent tubes are perfectly compatible and easy to retrofit. Variable, project-specific LED solutions with dimming are possible thanks to the selection of the appropriate driver (please order separately).

The existing housing and reflector can still be used, and old electrical components remain untouched. Lockable magnets on the LED module and the external driver allow for precise positioning of the mounting points within the housing. The included self-tapping screws, 0.5 mm² power cable (red/black), and pre-configured accessories save considerable time during installation.

▶ TENEO brochure

▶ TENEO assembly video

▶ T5/T8 Umrüst-Checkliste als praktischer Leitfaden für eine rechtskonforme Umrüstung

Operation is only possible in combination with a suitable LED driver. Functional reliability is only guaranteed with LED drivers approved by LAS.

The compatible LAS drivers are EL-certified and suitable for emergency power or DC operation.

For a legally compliant T5/T8 conversion, attention must be paid, among other things, to mechanical relief of the clamping points (strain relief). (ZVEI White Paper). We recommend using the offered TENEO Terminal block with integrated strain relief.

Other light color combinations such as 5000 / 6000 K are available as options.

Icon Abstrahlwinkel 120° Haupt / 200° Neben

Highlights Compact

Leuchtstoffröhre mit brennender Lunte, TENEO als zeitsparender Ersatz

Grafik TENEO-Prinzip für DC Variante mit externem Treiber als eigenständige Leuchte in der Leuchte mit VDE-Zertifizierung

Anwendung Rastergehäuse Shopbeleuchtung LED Sanierungseinsatz TENEO DC

Arretierbare Magnete auf der Leuchtenrückseite des LED Sanierungseinsatz TENEO — Lockable magnets on the back of the light for easy positioning in the housing

Leuchtenkopf mit Schieberegler zur Lichtfarbeinstellung 3000 oder 4000 K — Easy adjustment of two light color temperatures via slider

TENEO mit anderen T5-T8-Umrüstlösungen (Retrofit, Kernversionslampe, Universal-Umrüstsatz, Leuchtenspeziefischer Umrüstsatz) im Vergleich

Treiber auf Montageschlitten aud zwei selbstschneidenden Schrauben — Please select the external driver on the magnetic mounting slide according to the application and order separately!

3-poliger, vorkonfigurierter Anschluss-Klemmblock mit Ringschuh und Zugentlastung — Accessories: 3-/5-pin, pre-configured connection terminal block with through-wiring option

Zwei Magnetfüße für LED Sanierungseinsatz TENEO oder Zubehör — Accessories: Magnetic feet for mounting on the underside of the luminaire module, terminal block or mounting slide

Zwei Sockel mit Bohrloch und Schraube für LED Sanierungseinsatz TENEO — Accessories: Base with drill hole and screw for mounting on the underside of the luminaire module, terminal block or mounting slide

Höhenverstellbarer, magnetischer Abstandshalter am LED Sanierungseinsatz TENEO — Accessories: Height-adjustable, magnetic spacer for cases with limited space

Montageschlitten für Treiber mit magnetischen Füßen — Accessories: Mounting slide for drivers with magnetic feet

Universal LED retrofit solution for T5/T8 fluorescent tubes
Selection of external drivers for variable and Project-specific solutions with dimming options
Legally compliant, compatible “luminaire-in-luminaire” with VDE/CE certification
Continue using the casing – positioned between unused sockets
Selection of light color (2-stage) and flexible power regulation

LED retrofit insert with lockable magnetic feet, including power cable. Please order pre-assembled LED driver separately.

Article no.	Replacement for	Performance	Luminous flux	driver	Light color	Beam angle	Mass	Price
LS-TN30SW-15-E	T8 / 1.50 m	max. 30 W	up to 4800 lm	without	3000 / 4000 K	120° (max. 200°)	1480 x 28 x 28 mm	Check GH price Inquiries
LS-TN22SW-12-E	T8 / 1.20 m	max. 24 W	up to 3840 lm	without	3000 / 4000 K	120° (max. 200°)	1180 x 28 x 28 mm	Check GH price Inquiries
LS-TN09SW-06-E	T8 / 0.60 m	max. 9 W	up to 1440 lm	without	3000 / 4000 K	120° (max. 200°)	570 x 28 x 28 mm	Check GH price Inquiries
LS-TN09SW-04-E	T8 / 0.45 m	max. 9 W	up to 1400 lm	without	3000 / 4000 K	120° (max. 200°)	418 x 28 x 28 mm	Check GH price Inquiries
LS-TN30SW-14-E	T5 / 1.50 m	max. 30 W	up to 4800 lm	without	3000 / 4000 K	120° (max. 200°)	1430 x 28 x 28 mm	Check GH price Inquiries
LS-TN22SW-11-E	T5 / 1.15 m	max. 24 W	up to 3840 lm	without	3000 / 4000 K	120° (max. 200°)	1130 x 28 x 28 mm	Check GH price Inquiries

Accesories

Article no.	Designation	Price
LS-TD30-D	LED driver 1-10V/PWM dimming (9 - 30 W)	Check GH price Inquiries
LS-TD60-D	LED driver 1-10V/PWM dimming (30 – 60 W)	Check GH price Inquiries
LS-TD30-DA	LED driver DALI dimming (9 - 30 W)	Check GH price Inquiries
LS-TD60-DA	LED driver DALI dimming (30 - 60 W)	Check GH price Inquiries
LS-TN-AK	3-pin terminal block	Check GH price Inquiries
LS-TN-AK-DA	5-pin terminal block	Check GH price Inquiries
LS-TN-MF	2 magnetic feet	Check GH price Inquiries
LS-TN-SF	2 pieces of base	Check GH price Inquiries
LS-TN-VF	3 pieces of height-adjustable spacers	Check GH price Inquiries
LS-TN-MT	Mounting carriage for drivers	Check GH price Inquiries
