For installing the particularly flat round LED panel SUNOVA A minimum ceiling height of 35 mm is sufficient for these suspended ceilings. They are therefore perfectly suited for paneled or plasterboard ceilings. Pre-installed spring clips allow for quick and easy ceiling installation.
The desired light color is 3000 K. (WW), 4200 K(NW) or 5500 K (CW) The setting can be selected via a slider behind the high-quality driver. The aluminum frame, with its numerous fins, ensures good heat dissipation. The diffuser is made of UV-resistant polycarbonate.
DALI dimming available on request.
| type | Article no. | Performance | Luminous flux | Light color | Beam angle | Dimming | Ceiling cutout | Mass | Weight | Price |
|---|---|---|---|---|---|---|---|---|---|---|
 |
LS-SV8SW120 WP | 8 W | 600 lm | 3000 / 4200 / 5500 K | 120° | Phases | Ø 105 mm | Ø 120 x 12 mm | 120 g (without driver) |
|
 |
LS-SV10SW145W-P | 10 W | 750 ml | 3000 / 4200 / 5500 K | 120° | Phases | Ø 130 mm | Ø 148 x 12 mm | 195 g (without driver) |
|
 |
LS-SV12SW170W-P | 12 W | 900 ml | 3000 / 4200 / 5500 K | 120° | Phases | Ø 155 mm | Ø 170 x 12 mm | 220 g (without driver) |
|
 |
LS-SV15SW190W-P | 15 W | 1350 lm | 3000 / 4200 / 5500 K | 120° | Phases | Ø 175 mm | Ø 190 x 12 mm | 255 g (without driver) |
|
 |
LS-SV18SW225W-P | 18 W | 1440 lm | 3000 / 4200 / 5500 K | 120° | Phases | Ø 205 mm | Ø 225 x 12 mm | 345 g (without driver) |
|
|
|
LS-SV30SW300W-P | 30 W | 3200 lm | 3000 / 4200 / 5500 K | 120° | Phases | Ø 285 mm | Ø 300 x 12 mm | 620 g (without driver) |
|
|
|
LS-SV8SW120 W-4S | 8 W | 600 lm | 3000 / 4200 / 5500 K | 120° | 4-stage | Ø 105 mm | Ø 120 x 12 mm | 120 g (without driver) |
|
|
|
LS-SV10SW145W-4S | 10 W | 750 ml | 3000 / 4200 / 5500 K | 120° | 4-stage | Ø 130 mm | Ø 148 x 12 mm | 195 g (without driver) |
|
|
|
LS-SV12SW170W-4S | 12 W | 900 ml | 3000 / 4200 / 5500 K | 120° | 4-stage | Ø 155 mm | Ø 170 x 12 mm | 220 g (without driver) |
|
|
|
LS-SV15SW190W-4S | 15 W | 1350 lm | 3000 / 4200 / 5500 K | 120° | 4-stage | Ø 175 mm | Ø 190 x 12 mm | 255 g (without driver) |
|
|
|
LS-SV18SW225W-4S | 18 W | 1440 lm | 3000 / 4200 / 5500 K | 120° | 4-stage | Ø 205 mm | Ø 225 x 12 mm | 345 g (without driver) |
|
|
|
LS-SV30SW300W-4S | 30 W | 3200 lm | 3000 / 4200 / 5500 K | 120° | 4-stage | Ø 285 mm | Ø 300 x 12 mm | 620 g (without driver) |
|
