LED universal module FLEXO IP

Light strip concept with IP65 protection for special applications

The LED universal module FLEXO IP complements the innovative FLEXO series, which stands for efficient and convenient light strip renovation. With its dust- and water-resistant IP 65-rated housing, the versatile module is ideal for demanding applications involving fumes or dirt in industry and trade. Whether in production facilities, warehouses, sawmills, carpentry shops, or workshops, the universal module impresses with its robustness and quick installation.

A wide range of variants offers the optimal solution for many situations: beam angles of 60°, 90°, or 110°, clear or opal covers, and models with DALI options. FLEXO IP is not only an IP65-protected retrofit solution, but also presents itself as a flexible, durable, and cost-effective alternative to traditional damp-proof diffuser luminaires.

▶ FLEXO IP brochure

Highlights Compact

Anwendung Industriehalle mit Dämpfen LED Universalmodul FLEXO IP

Anwendung Schreinerei mit fliegenden Sägespänen LED Universalmodul FLEXO IP — Ideal for demanding environments with dust, fumes and dirt

Zeitsparendes Installationsprinzip mit dem Click-Slide-System für LED Universalmodul FLEXO IP — Simple, time-saving one-person assembly with the Click-Slide system

IP65-geschützte Treiberbox des LED Universalmodul FLEXO IP mit 3 separaten Öffnungen für Einstellungen — IP65-protected driver box with three separate openings for settings

Abdeckung klar + Linse, 60° Abstrahlwinkel — Clear cover + lens · 60° beam angle

Abdeckung klar + Linse, 90° Abstrahlwinkel — Clear cover + lens · 90° beam angle

Abdeckung klar + Diffusor, 110° Abstrahlwinkel — Clear cover + diffuser · 110° beam angle

Abdeckung opal, 110° Abstrahlwinkel — Opal cover · 110° beam angle

IP65-protected light line solution with quick, tool-free installation
Compatible with many common mounting rails
Very high light output with up to 10 400 lm and 170 lm/watt
Driver box with protected, easily accessible adjustment controls
Easy control of phase, power and light color temperature
Variety of variants with selection of DALI, beam angles & covers

Article no.	Performance	Luminous flux	Light color	Beam angle	Dimming	cover	Mass	Price
LS-FP60SW60	30 / 40 / 50 / 60 W	max. 10400 lm	4000 / 5000 / 6000 K	60°	DIP	clear + lens	1527 x 65 x 85 mm	Check GH price Inquiries
LS-FP60SW90	30 / 40 / 50 / 60 W	max. 10400 lm	4000 / 5000 / 6000 K	90°	DIP	clear + lens	1527 x 65 x 85 mm	Check GH price Inquiries
LS-FP60SW108	30 / 40 / 50 / 60 W	max. 9800 lm	4000 / 5000 / 6000 K	110°	DIP	clear + diffuser	1527 x 65 x 85 mm	Check GH price Inquiries
LS-FP60SW110	30 / 40 / 50 / 60 W	max. 9800 lm	4000 / 5000 / 6000 K	110°	DIP	opal	1527 x 65 x 85 mm	Check GH price Inquiries
LS-FP60SW60-DA	30 / 40 / 50 / 60 W	max. 10400 lm	4000 / 5000 / 6000 K	60°	DIP / DALI	clear + lens	1527 x 65 x 85 mm	Check GH price Inquiries
LS-FP60SW90-DA	30 / 40 / 50 / 60 W	max. 10400 lm	4000 / 5000 / 6000 K	90°	DIP / DALI	clear + lens	1527 x 65 x 85 mm	Check GH price Inquiries
LS-FP60SW108-DA	30 / 40 / 50 / 60 W	max. 9800 lm	4000 / 5000 / 6000 K	110°	DIP / DALI	clear + diffuser	1527 x 65 x 85 mm	Check GH price Inquiries
LS-FP60SW110-DA	30 / 40 / 50 / 60 W	max. 9800 lm	4000 / 5000 / 6000 K	110°	DIP / DALI	opal	1527 x 65 x 85 mm	Check GH price Inquiries

Accesories

Article no.	Designation	Price
LS-MF-S15	FLEXO support rail 1.5 m	Check GH price Inquiries → Details
LS-MF-S30	FLEXO support rail 3.0 m	Check GH price Inquiries → Details
LS-MF-BA	Plastic blind cover for 1.5 m support rail, easy to cut to size	Check GH price Inquiries → Details
LS-MF-VE	Mounting rail quick connector, including screws, dimensions: 230 x 62 x 47 mm	Check GH price Inquiries → Details
LS-MF-SB	Blank cover for 1.5 m mounting rail, plastic, dimensions: 1527 x 65 x 20 mm – discontinued item	Check GH price Inquiries → Details
LS-MF-SV	Mounting rail connecting element, including screws – discontinued item	Check GH price Inquiries → Details
LS-MF-END	Mounting rail end cap, 2 pieces, dimensions: 65 x 12 x 50 mm	Check GH price Inquiries → Details
LS-MF-TA	Mounting rail hanger, height adjustable, with safety screw and cable holder	Check GH price Inquiries → Details
LS-MF-ON	Suspension set for support rail hanger LS-MF-TA, contains: 2 x carabiners, 2 x ceiling mounting brackets and 2 x chains (length 2400 mm)	Check GH price Inquiries → Details
